Cutting Diameter (DC) | 3/32″ | End Shape | Square |
Connection Diameter Machine Side (DCONMS) | 1/8″ | Usable Length (LU) | 3/16″ |
Depth of Cut Maximum (APMX) | 3/16″ | Tool Type | Center Cut|Single-End |
Overall Length (OAL) | 1-1/2″ | Length Group | Stub |
Cutting Edge Material | Carbide | Style | Stub |
Coating | AlTiN | Decimal Equivalent | 0.0938″ |
Flute Count (NOF) | 4 | Measurement Type | Inch |
Shank Type | Round | Series/List # | 414 |
Product Features
Remarks | •Solid Carbide General Purpose, 2- & 4- Flute End Mills
•Stub Length 4-Flute Single End Mills
•Standard Micro Grain Carbide | Country of Origin | USA |
Shipping Info
LocalField10
0
Package Length
2.70000
Package Width
.50000
Package Weight
0.015
